General Information
| Other name(s): | Skyggelog Footbridge |
|---|---|
| Status: | in use |
Project Type
| Function / usage: |
Bicycle and pedestrian bridge |
|---|---|
| Structure: |
Three-span continuous girder bridge |
| Support conditions: |
for registered users |
| Plan view: |
Structurae Plus/Pro - Subscribe Now! |
| Structure: |
Single-cell box girder bridge Haunched girder bridge |
Location
Technical Information
Dimensions
| total length | 79.500 m | |
| span | 60.000 m | |
| span lengths | 6.000 m - 60.000 m - 6.000 m | |
| number of spans | 3 | |
| walkway width | 6.000 m | |
| deck | deck depth | 0.890 - 1.900 m |
| length | 72.000 m | |
| deck width | 6.295 m | |
| piles | length | max. 30 m |
Materials
| deck |
steel
|
|---|---|
| abutments |
reinforced concrete
|
Participants
Owner
Architecture
Structural design
Contractor
Relevant Web Sites
There currently are no relevant websites listed.
Relevant Publications
- (2022): A Challenging Slenderness. Nonnekloppen Bridge in Bergen. Presented at: Footbridge 2022: Creating Experience, Madrid, Spain, 07-09 September 2022.
- (2014): Skyggelog Footbridge, Bergen. Presented at: Footbridge 2014 - Past, Present & Future, London, 16-18 July 2014.
