General Information
| Other name(s): | Darul Hana Bridge; Harmony Bridge |
|---|---|
| Beginning of works: | October 2016 |
| Completion: | May 2017 |
| Status: | in use |
Project Type
| Function / usage: |
Bicycle and pedestrian bridge |
|---|---|
| Structure: |
Three-span cable-stayed bridge |
| Plan view: |
Structurae Plus/Pro - Subscribe Now! |
| Material: |
Steel bridge |
| Support conditions: |
for registered users |
| Secondary structure(s): |
Structurae Plus/Pro - Subscribe Now! |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
| Secondary structure(s): |
Structurae Plus/Pro - Subscribe Now! |
Location
Technical Information
Dimensions
| total length | 337 m | |
| bridge surface | 1 095 m² | |
| walkway width | 3.25 m | |
| main bridge | ||
|---|---|---|
| main span | 133 m | |
| total length | 267 m | |
| deck | deck depth | 1.62 m |
| pylons | height | 50 m |
| length | 64 m | |
| number | 2 | |
Cost
| cost of construction | Malaysian ringgit 35 000 000 |
Materials
| pylon |
steel
|
|---|---|
| deck truss |
steel tubes
(S 355)
|
Participants
Structural engineering
Checking engineering
Co-contractor
Steel construction
Relevant Web Sites
Relevant Publications
- (2017): The Golden Bridge - A Footbridge Over the Sarawak River. Presented at: Footbridge 2017 Berlin - Tell A Story, 6-8.9.2017, Technische Universität Berlin (TU Berlin).
- About this
data sheet - Structure-ID
20074356 - Published on:
10/12/2017 - Last updated on:
27/09/2022
