General Information
| Other name(s): | Cebu–Cordova Link Expressway; Third Cebu–Mactan Bridge |
|---|---|
| Beginning of works: | 2017 |
| Completion: | 30 April 2022 |
| Status: | in use |
Project Type
| Function / usage: |
Road bridge |
|---|---|
| Structure: |
Three-span cable-stayed bridge Cable-stayed bridge with semi-fan system |
| Material: |
Prestressed concrete bridge |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
| Secondary structure(s): |
Structurae Plus/Pro - Subscribe Now! |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
| Secondary structure(s): |
Structurae Plus/Pro - Subscribe Now! |
Location
| Location: |
Cebu City, Cebu, Philippines Cordova, Cebu, Philippines |
|---|---|
| Coordinates: | 10° 17' 11.48" N 123° 53' 57.48" E |
Technical Information
Dimensions
| total length | 8 900 m | |
| number of lanes | 2 x 2 | |
| main bridge | ||
|---|---|---|
| main span | 390 m | |
| total length | 653.00 m | |
| span lengths | 6.50 m - 64.4 m - 60.6 m - 390 m - 60.6 m - 64.4 m - 6.50 | |
| vertical navigation clearance | 51 m | |
| deck | deck depth | 3.50 m |
| deck width | 26.90 m | |
| piers | height | 44.32 m |
| pylons | height | 139 m |
| stay cables | number | 56 |
Materials
| deck |
prestressed concrete
|
|---|---|
| piers |
reinforced concrete
|
| pylons |
reinforced concrete
|
Participants
Design
Architecture
Consulting engineers
Detailed design
- Carlos Fernández Casado S.L. (main bridge)
- Sener (approach viaducts)
Checking engineering
Co-contractor
Stay cables
Prestressing
Bearings
Expansion joints
Formwork
Form travelers
Lifting
Relevant Web Sites
Relevant Publications
- (2023): Design features of the Cable-stayed Bridge between the islands of Cebu and Mactan (Republic of the Philippines). Presented at: IABSE Symposium: Long Span Bridges, Istanbul, Turkey, 26-28 April 2023, pp. 878-886.
- (2023): Special Construction features of the Cable-Stayed Bridge between the islands of Cebu and Mactan (Republic of the Philippines). Presented at: IABSE Symposium: Long Span Bridges, Istanbul, Turkey, 26-28 April 2023, pp. 691-699.
