General Information
Project Type
| Structure: |
Half-through arch bridge |
|---|---|
| Function / usage: |
Road bridge Monorail bridge |
| Material: |
Steel bridge Structurae Plus/Pro - Subscribe Now! |
Location
Technical Information
Dimensions
| arch span | 420 m | |
| main bridge | ||
|---|---|---|
| total length | 800 m | |
| span lengths | 88 m - 102 m - 420 m - 102 m - 88 m | |
| deck width | 36.500 m | |
| number of spans | 5 | |
Quantities
| structural steel | 25 900 t | |
| concrete volume | 53 000 m³ |
Materials
| piers |
prestressed concrete
|
|---|---|
| arch |
steel
|
Participants
Design
Main contractor
Relevant Web Sites
There currently are no relevant websites listed.
Relevant Publications
- (2009): China's Major Bridges. Presented at: IABSE Workshop: Recent Major Bridges, Shanghai, China, 11-12 May 2009, pp. 1-24.
- (2010): Design and Construction of the Main Spans of the Chongqing Caiyuanba Bridge, China. In: Structural Engineering International, v. 20, n. 3 (August 2010), pp. 296-298.
- (2004): Design of the main spans of the Chongqing Caiyuanba Bridge. Presented at: Steelbridge 2004, Millau, 23-25 June 2004, pp. 101-102.
- (2004): Design of the Main Spans of the Chongqing Caiyuanba Bridge. Presented at: IABSE Symposium: Metropolitan Habitats and Infrastructure, Shanghai, China, 22-24 September 2004, pp. 86-87.
- (2007): On the record. In: Bridge Design & Engineering, n. 48 (3rd Quarter 2007), pp. 34-36.
