General Information
Project Type
| Function / usage: |
Railroad (railway) tunnel |
|---|---|
| Structure: |
Tunnel |
| Construction method: |
Tunnel shield Immersed tube method Cut-and-cover method |
Location
| Location: |
Berlin-Kreuzberg, Friedrichshain-Kreuzberg, Berlin, Germany Berlin-Moabit, Mitte, Berlin, Germany Berlin-Tiergarten, Mitte, Berlin, Germany |
|---|---|
| Underneath of: |
|
| Coordinates: | 52° 29' 53.92" N 13° 22' 21.83" E |
| Coordinates: | 52° 31' 44.73" N 13° 21' 58.46" E |
Technical Information
Dimensions
| tunnel length | 3 415 m | |
| number of tubes | 4 |
Design Loads
| design speed | max. 120 km/h |
Participants
Relevant Web Sites
Relevant Publications
- (1997): New Rail Tunnels under Central Berlin. In: Structural Engineering International, v. 7, n. 4 (November 1997), pp. 242-244.
- About this
data sheet - Structure-ID
20012337 - Published on:
29/06/2004 - Last updated on:
28/05/2021
