General Information
| Completion: | 1985 |
|---|---|
| Status: | in use |
Project Type
| Structure: |
Three-span suspension bridge |
|---|---|
| Function / usage: |
Motorway bridge / freeway bridge Railroad (railway) bridge |
| Material: |
Steel bridge |
Location
Technical Information
Dimensions
| main span | 876 m | |
| length of side spans | 312.0 m / 312.2 m | |
| sag | 82 m | |
| total length | 1 629 m | |
| tower height | 128.3 m | |
| span lengths | 93 m - 330 m - 876 m - 330 m | |
| number of spans | 4 |
Quantities
| structural steel | 63 324 t |
Materials
| cables |
steel
|
|---|---|
| deck |
steel
|
| anchorages |
concrete
|
Relevant Web Sites
Relevant Publications
- (2002): Bridges - Ponts - Brücken. Atrium, Mexico City (Mexico), pp. 82-85.
- (1986): Ohnaruto Bridge. In: IABSE Structures, v. 10 (February 1986).
- (1986): Vibration test of Ohnaruto bridge to confirm wind-proofness. Presented at: IABSE Symposium: Safety and Quality Assurance of Civil Engineering Structures = Sécurité et assurance de la qualité des structures de génie civil = Sicherheit und Qualitätssicherung von Ingenieurbauwerken, Tokio, Japan, 1986.
- About this
data sheet - Structure-ID
20000433 - Published on:
08/10/1999 - Last updated on:
02/01/2018
