General Information
Project Type
| Structure: |
Haunched girder bridge |
|---|---|
| Function / usage: |
Bicycle and pedestrian bridge |
| Material: |
Weathering steel bridge |
| Plan view: |
Structurae Plus/Pro - Subscribe Now! |
| Support conditions: |
for registered users |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
Location
| Location: |
Konstanz, Konstanz (Kreis), Baden-Württemberg, Germany |
|---|---|
| Crosses: |
|
| Coordinates: | 47° 40' 5.56" N 9° 10' 26.50" E |
Technical Information
Dimensions
| main span | 70.02 m | |
| width | 8.2 m | |
| total length | 163.38 m | |
| girder depth | 1.32 - 2.97 m |
Materials
| piers |
reinforced concrete
|
|---|---|
| girder |
weathering steel
|
| abutments |
reinforced concrete
|
Participants
Currently there is no information available about persons or companies having participated in this project.
Relevant Web Sites
There currently are no relevant websites listed.
Relevant Publications
- (1994): Geh- und Radwegbrücke aus wetterfestem Baustahl über den Seerhein bei Konstanz. In: Bauingenieur, v. 69, n. 2 (February 1994), pp. 81-89.
- About this
data sheet - Structure-ID
20011410 - Published on:
04/01/2004 - Last updated on:
22/07/2020
