General Information
Project Type
| Structure: |
Cable-stayed bridge with semi-fan system |
|---|---|
| Function / usage: |
Bicycle and pedestrian bridge |
| Material: |
Steel bridge |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
| Secondary structure(s): |
Structurae Plus/Pro - Subscribe Now! |
Location
| Location: |
Sremska Mitrovica, Srem , Serbia Mačvanska Mitrovica, Srem , Serbia |
|---|---|
| Crosses: |
|
| Coordinates: | 44° 57' 57.50" N 19° 36' 5.08" E |
Technical Information
Dimensions
| span lengths | 2 x 35.00 m - 192.50 m - 35.00 m | |
| number of spans | 4 | |
| deck | deck width | 5.5 m |
Quantities
| structural steel | 388 418 kg | |
| concrete volume | 2 760 m³ | |
| prestressing steel | 1 630 kg | |
| reinforcing steel | 263 500 kg |
Materials
| superstructure |
steel
|
|---|---|
| pylons |
steel
|
Participants
Design
- Gradimir Sreckovic (designer)
- Dragoljub Isailovic (designer)
Design engineers
- B. Grujic (design engineer) (cables)
- B. Radovanovic (design engineer)
- Lj. Mijovic (design engineer)
- M. Masovic (design engineer)
- M. Miskovic (design engineer)
- Dragomir Lukic (design engineer)
Contractor
(role unknown)
Relevant Web Sites
There currently are no relevant websites listed.
Relevant Publications
- (1998): Cable-stayed pedestrian bridge "St. Irinej" over river Sava. Presented at: 3. Internationale Donaubrückenkonferenz, 3rd International Conference on Bridges across the Danube, 29-30/10/1998, Regensburg, Germany, pp. 153-164.
- About this
data sheet - Structure-ID
20003731 - Published on:
20/06/2002 - Last updated on:
16/10/2016
