General Information
| Name in local language: | Pont de Rigny |
|---|---|
| Beginning of works: | May 2011 |
| Completion: | 26 November 2011 |
| Status: | in use |
Project Type
| Structure: |
Multiple Kingpost truss bridge |
|---|---|
| Function / usage: |
Road bridge |
| Material: |
Steel-reinforced concrete composite bridge Structurae Plus/Pro - Subscribe Now! |
| Support conditions: |
for registered users |
| Plan view: |
Structurae Plus/Pro - Subscribe Now! |
| Deck levels: |
Structurae Plus/Pro - Subscribe Now! |
Location
| Location: |
Rigny, Haute-Saône (70), Bourgogne-Franche-Comté, France |
|---|---|
| Crosses: |
|
| Coordinates: | 47° 28' 12.35" N 5° 37' 56.39" E |
Technical Information
Dimensions
| width | 4.10 m | |
| total length | 141.5 m | |
| number of lanes | 1 | |
| roadway / carriageway width | 2.50 m | |
| walkway width | 1.50 m | |
| deck | girder depth | 0.80 m |
Materials
| deck slab |
reinforced concrete
|
|---|---|
| main girders |
steel
|
Participants
Relevant Web Sites
- About this
data sheet - Structure-ID
20079407 - Published on:
25/05/2020 - Last updated on:
23/09/2025
