General Information

Beginning of works: 2011
Completion: 2013
Status: completed

Project Type

Location

Location: , , ,
Coordinates: 50° 31' 20" N    10° 59' 31" E
Show coordinates on a map

Technical Information

Dimensions

width 14.10 m
total length 203.45 m
height above valley floor or water ca. 54 m
arch arch span 107.45 m

Design Loads

design speed 300 km/h

Materials

deck prestressed concrete
arch reinforced concrete

Participants

Owner

Relevant Web Sites

There currently are no relevant websites listed.

  • About this
    data sheet
  • Structure-ID
    20064927
  • Published on:
    31/03/2013
  • Last updated on:
    05/02/2016
