General Information
Project Type
| Structure: |
Deck truss bridge |
|---|---|
| Material: |
Prestressed concrete bridge |
| Plan view: |
Structurae Plus/Pro - Subscribe Now! |
| Support conditions: |
for registered users |
| Material: |
Structurae Plus/Pro - Subscribe Now! |
| Function / usage: |
upper deck: Motorway bridge / freeway bridge lower deck: Bicycle and pedestrian bridge |
Location
| Location: |
Weyarn, Miesbach (Kreis), Bavaria, Germany |
|---|---|
| Crosses: |
|
| Carries: |
|
| Part of: | |
| Next to: |
Mangfall Bridge (1979)
|
| See also: |
Mangfall Bridge (1935)
|
| Coordinates: | 47° 52' 7.87" N 11° 47' 12.54" E |
Technical Information
Dimensions
| total length | 288 m | |
| span lengths | 90 m - 108 m - 90 m | |
| number of spans | 3 | |
| height above valley floor or water | 63 m |
Materials
| piers |
reinforced concrete
|
|---|---|
| truss |
prestressed concrete
|
| abutments |
reinforced concrete
|
Participants
Owner
Client
Architecture
- Gerd Lohmer (architect)
Alternative design
-
Dyckerhoff & Widmann AG
- Ulrich Finsterwalder (designer)
Structural engineering
-
Dyckerhoff & Widmann AG
- Ulrich Finsterwalder (structural engineer)
Contractor
Relevant Web Sites
There currently are no relevant websites listed.
Relevant Publications
- (1963): Algunos aspectos del proyecto de grandes puentes. In: Hormigón pretensado, v. 14, n. 66 (1st Quarter 1963), pp. 12-22.
- (1983): Brücken in Deutschland. HB Verlagsgesellschaft, Hamburg (Germany), pp. 27.
- (1965): Die Entwicklung des freien Vorbaus von Spannbetonbrücken. In: Bauingenieur, v. 40, n. 3 (March 1965), pp. 85-91.
- (1966): Große Konstrukteure 1. Freyssinet, Maillart, Dischinger, Finsterwalder. Verlag Ullstein GmbH, Berlin (Germany), pp. 244-245.
- (1969): Puentes pretensados, en voladizo libre, construidos por el sistema Dywidag. In: Hormigón y acero, v. 20, n. 90 (1st Quarter 1969), pp. 27-47.
- About this
data sheet - Structure-ID
20001427 - Published on:
09/04/2001 - Last updated on:
21/04/2016
