General Information
| Completion: | 2016 |
|---|---|
| Status: | in use |
Project Type
| Structure: |
Bowstring-arch-truss bridge |
|---|---|
| Function / usage: |
Bicycle and pedestrian bridge |
| Material: |
Steel bridge |
Location
| Location: |
Hamm, North Rhine-Westphalia, Germany |
|---|---|
| Crosses: |
|
| See also: |
Lippeparkbrücke über den Datteln-Hamm-Kanal (2016)
|
| Coordinates: | 51° 40' 35.88" N 7° 45' 17.83" E |
Technical Information
Dimensions
| width | 5.2 m | |
| arch span | 77 m |
Materials
| deck |
steel
|
|---|---|
| arches |
steel
|
| abutments |
reinforced concrete
|
Participants
Object planning
Structural engineering
Site supervision
Relevant Web Sites
There currently are no relevant websites listed.
- About this
data sheet - Structure-ID
20071627 - Published on:
26/09/2016 - Last updated on:
28/09/2016
